Specifications*:

Engine size:

839

Cylinders:

2

hp/kW:

75/ 55

Vehicle weight (kg):

249

Seat height (mm):

780

Valve clearance (intake):

KALT 0,15 MM

Valve clearance (exhaust):

KALT 0,15 MM

Engine idle speed:

1250 ± 100 U/MIN

Carburettor air screw:

EINSPRITZUNG 38 MM

Tyre pressure (front):

2,5 BAR

Tyre pressure (rear):

2,75 BAR

Spark plug 1:

NGK CR7EKB

Electrode gap:

0,7-0,9 MM

Fork tube diam.:

41 MM TELEGABEL

Chain/Final drive:

KETTE

Capacities*:

Fork oil per rod:

295 ± 3ML SAE 7,5W

Engine oil w/o filter:

2,4 L SAE 5W-40

Engine oil with filter:

2,6 L VOLLSYNTH.

Gear oil:

80W-90 GL-5

Brake fluid:

DOT 4

Fuel:

18,8 LITER

Coolant:

CA. 2,4 LITER
