Specifications*:

Engine size:

449

Cylinders:

2

hp/kW:

60/44, 55/40, 19/14

Vehicle weight (kg):

122

Seat height (mm):

918

Valve clearance (intake):

KALT 0,07-0,12 MM

Valve clearance (exhaust):

KALT 0,17-0,22 MM

Engine idle speed:

1900 ± 100 U/MIN

Carburettor air screw:

EINSPRITZUNG

Tyre pressure (front):

1,8 (1,9) BAR

Tyre pressure (rear):

2,0 (2,2) BAR

Spark plug 1:

NGK CR8EKB

Spark plug 2:

NGK CR8EIX

Electrode gap:

NACH HERST.ANGABEN

Fork tube diam.:

48 MM USD-GABEL

Chain/Final drive:

KETTE

Capacities*:

Fork oil per rod:

SAE 10W

Engine oil w/o filter:

1,3 LITER

Engine oil with filter:

SAE 10W-60

Brake fluid:

DOT 4

Fuel:

7,5 LITER

Coolant:

1,1 LITER
