Spare parts and accessories for BMW K 1200 LT K1200LT

2004 - 2009

Specifications*

Engine size:

1171

Cylinders:

hp/kW:

116/85

Vehicle weight (kg):

378

Seat height (mm):

770

Valve clearance (intake):

KALT 0,15-0,20 MM

Valve clearance (exhaust):

KALT 0,25-0,30 MM

Engine idle speed:

1000-1050 U/MIN

Carburettor air screw:

EINSPRITZUNG 34MM

Tyre pressure (front):

2,5 BAR

Tyre pressure (rear):

2,9 (3,2) BAR

Spark plug 1:

NGK DCPR7E

Spark plug 2:

NGK DCPR7EIX

Electrode gap:

0,8 MM

Fork tube diam.:

41 MM TELELEVER

Chain/Final drive:

KARDAN

Specifications*

Engine size:

1171

Cylinders:

hp/kW:

116/85

Vehicle weight (kg):

378

Seat height (mm):

770

Valve clearance (intake):

KALT 0,15-0,20 MM

Valve clearance (exhaust):

KALT 0,25-0,30 MM

Engine idle speed:

1000-1050 U/MIN

Carburettor air screw:

EINSPRITZUNG 34MM

Tyre pressure (front):

2,5 BAR

Tyre pressure (rear):

2,9 (3,2) BAR

Spark plug 1:

NGK DCPR7E

Spark plug 2:

NGK DCPR7EIX

Electrode gap:

0,8 MM

Fork tube diam.:

41 MM TELELEVER

Chain/Final drive:

KARDAN

Capacities*

Fork oil per rod:

470 ML SAE 10W

Engine oil w/o filter:

SAE 5W-40

Engine oil with filter:

3,5 L MIN. API SL

Gear oil:

600ML 75W-140 GL-5

Brake fluid:

DOT 4

Final drive oil:

230ML 75W-140 GL-5

Fuel:

24,0 LITER

Coolant:

3,1 LITER

Capacities*

Fork oil per rod:

470 ML SAE 10W

Engine oil w/o filter:

SAE 5W-40

Engine oil with filter:

3,5 L MIN. API SL

Gear oil:

600ML 75W-140 GL-5

Brake fluid:

DOT 4

Final drive oil:

230ML 75W-140 GL-5

Fuel:

24,0 LITER

Coolant:

3,1 LITER

Test reports and information

MOTORRAD 9/04

MOTOTRAVELLER 1/05

MOTORRAD 18/05

Find used value:

DAT GmbH

Test reports and information*

MOTORRAD 9/04

MOTOTRAVELLER 1/05

MOTORRAD 18/05

Find used value:

DAT GmbH

Data or products for your motorcycle missing from the database? Found an error? Please let us know. Go to form

81 articles

Delo

Microfleece battery

€139.99¹

Delo

Standard Battery

€69.99¹ €68.22¹

All Balls Racing

Wheel Bearing Set

€41.99¹

Tourmax

Steering Head Bearing

€41.99¹

Brembo

Brake-Discs Fixed with ABE

€179.99¹

TRW

Lucas Brake Discs

from €119.95¹

TRW

Racing Brake Discs Front

from €119.95¹

TRW

Fixing-Kit For BMW Brake-Discs

€19.95¹

TRW

Brake-Pads Sinter with ABE

€39.95¹

-13%

TRW

Brakepads Organic

€33.95¹ €29.23¹

All Balls Racing

FORK SEAL SET

€29.99¹

Fork Seal Set

€9.99¹

-21%

Sachs Motorrad

Sachs clutch discs for BMW

€140.95¹ €109.99¹

-36%

Sachs Motorrad

Sachs clutch diaphragm springs

€101.95¹ €64.95¹

-18%

Sachs Motorrad

Sachs clutch housing cover

€195.95¹ €159.99¹

-21%

Sachs Motorrad

Sachs clutch pressure plate

€113.95¹ €89.99¹

TRW

Friction Plates Sets

€89.99¹

-22%

K&N

High-Flow Airfilter

€94.99¹ €74.07¹

mahle

Air Filters

€28.99¹

Champion

Oil Filter

€12.99¹

K&N

OIL FILTER

€14.99¹

Louis

Aluminium washer set for oil

€1.99¹

Louis

Copper ring set for oil

€1.99¹

Louis

Megnetic Oil Drain Plug

€4.99¹

stahlbus

Oil Drain Valve

€36.95¹

NGK

Spark Plug

€6.99¹

NGK

Iridium Spark Plug

€17.99¹

EiLER

eil-zurr Motorcycle Securing

€249.00¹

Castrol

Brake fluid

€14.99¹

-40%

Motul

Brake Fluid DOT 3 & 4, 0,5L

€7.99¹ €4.78¹

(1 l = €9.56¹)

Motul

Brake Fluid DOT 3 & 4, 1 L

€12.99¹

Motul

Brake Fluid DOT 4 LV

€6.99¹

(1 l = €13.98¹)

Motul

RBF 660 Racing Brake Fluid

€14.99¹

(1 l = €29.98¹)

Motul

RBF 700 FL Racing Brake Fluid

€19.99¹

(1 l = €39.98¹)

PROCYCLE

Brake Fluid

€9.99¹

TRW

Brake Fluid

€19.99¹

TRW

Brake Fluid

€4.99¹

(100 ml = €2.00¹)

Castrol

Power1 Racing 4T

from €14.99¹

-9%

Motul

7100 4T Engine Oil SAE 5W-40, 1 Liter

€16.99¹ €15.30¹

-10%

Motul

7100 4T Engine Oil SAE 5W-40, 4 Liter

€59.99¹ €53.51¹

(1 l = €13.38¹)

PROCYCLE

Engine Oil 4T SAE 5W-40, 1 Litre

€12.99¹

PROCYCLE

Engine Oil 4T SAE 5W-40, 4 Litre

€34.99¹

(1 l = €8.75¹)

Castrol

Fork Oil

€7.99¹

(1 l = €15.98¹)

-12%

Motul

Expert Fork Oil Technosynthese

€14.99¹ €13.15¹

Motul

Factory Line Fork Oil 10W, 1 litre

€17.99¹ €17.44¹

Öhlins

Fully synthetic fork oil

€25.00¹

Wilbers

Fork oil zero friction SAE 5W up to 20W

€25.00¹

(1 l = €25.00¹)

Castrol

MTX Transmission Oil

€19.99¹

Tip

Tips for DIY mechanics

We've compiled an extensive list of DIY tips for you, which will help you to do the most important service work yourself.
Find out more >

Find out more

* Louis has taken great care in compiling the specifications and associated products. They apply to the model of the selected vehicle that is sold in Germany. The specifications of models sold in other countries may differ. Louis does not accept any responsibility for the accuracy of the information provided. Prior to installation, you should consult your motorcycle's handbook and/or seek information from the manufacturer.

Specifications, spare parts and accessories for BMW K 1200 LT (K1200LT)

Are you planning to maintain and service your own BMW K 1200 LT (K1200LT)? If so, Louis will provide you with all the information you need. What type of engine oil and which brake fluid should you use? Which are the right spark plugs? What are the correct tyre pressures and valve clearances? We give you the answers to all the important questions about your motorcycle. In addition, we offer a carefully compiled list of all the wearing parts, add-ons and accessories available in our range specifically for your BMW K 1200 LT (K1200LT). So we are a one-stop shop where you can get all the information you need and the right product quickly and easily.
