Specifications*:

Engine size:

601

Cylinders:

1

hp/kW:

34/25

Vehicle weight (kg):

171

Seat height (mm):

800

Valve clearance (intake):

KALT 0,03 MM

Valve clearance (exhaust):

KALT 0,05 MM

Carburettor air screw:

1,0 AUSDREHUNGEN

Tyre pressure (front):

1,8 BAR

Tyre pressure (rear):

2,0 (2,2) BAR

Spark plug 1:

NGK BKR7EIX '96-97

Spark plug 2:

NGK BCP7ES '98-

Electrode gap:

GEM.HERSTELLERANG.

Fork tube diam.:

45 MM TELEGABEL

Front/rear sprockets:

15/45 ZÄHNE

Chain/Final drive:

114 GLIEDER

Capacities*:

Fork oil per rod:

655 ML SAE 7,5W

Engine oil w/o filter:

SAE 10W-40

Engine oil with filter:

2,1 LITER

Brake fluid:

DOT 4

Fuel:

20,0 LITER

Coolant:

LUFTGEKÜHLT

Test reports and information*:
