Specifications*:

Engine size:

998

Cylinders:

4

hp/kW:

175/128

Vehicle weight (kg):

196

Seat height (mm):

825

Valve clearance (intake):

KALT 0,17-0,22 MM

Valve clearance (exhaust):

KALT 0,15-0,24 MM

Engine idle speed:

1100 ± 50 U/MIN

Carburettor air screw:

EINSPRITZUNG

Tyre pressure (front):

2,5 BAR

Tyre pressure (rear):

2,9 BAR

Spark plug 1:

NGK CR9EIA-9

Electrode gap:

0,9 MM

Fork tube diam.:

43 MM USD-GABEL

Front/rear sprockets:

17/39 ZÄHNE

Chain/Final drive:

110 GLIEDER

Capacities*:

Fork oil per rod:

CA. 570 ML SAE 10W

Engine oil w/o filter:

2,7 L SAE 10W-40

Engine oil with filter:

3,0 L MIN. API SG

Brake fluid:

DOT 4

Fuel:

17,0 LITER

Coolant:

2,5 LITER
