Spare parts and accessories for CAGIVA RAPTOR/V-RAPTOR 1000 - RAPTOR/V

My Bike
RAPTOR/V-RAPTOR 1000
2000 - 2005
Find another bike
Specifications *
Cylinders:
2
hp/kW:
105/77
Seat height (mm):
770
Valve clearance (intake):
KALT 0,10-0,20 MM
Valve clearance (exhaust):
KALT 0,20-0,30 MM
Engine idle speed:
1200 ± 100 U/MIN
Carburettor air screw:
EINSPRITZUNG
Tyre pressure (front):
2,3 (2,5) BAR
Tyre pressure (rear):
2,5 (2,7) BAR
Spark plug 1:
NGK CR8EK
Spark plug 2:
NGK CR8EIX
Electrode gap:
0,9 MM
Fork tube diam.:
43 MM USD-GABEL
Front/rear sprockets:
16/40 ZÄHNE
Chain/Final drive:
106 GLIEDER
Capacities *
Fork oil per rod:
425 ML SAE 7,5W
Engine oil w/o filter:
3,1 L. SAE 10W-40
Engine oil with filter:
3,3 LITER
Brake fluid:
DOT 4
Fuel:
17,0 LITER
Coolant:
2,0 LITER
* We acquire the data with care, but without any guarantee
Louis has taken great care in compiling the specifications and associated products. They apply to the model of the selected vehicle that is sold in Germany. The specifications of models sold in other countries may differ. Louis does not accept any responsibility for the accuracy of the information provided. Prior to installation, you should consult your motorcycle's handbook and/or seek information from the manufacturer.
