Spare parts and accessories for HONDA XL 600 V TRANSALP - PD06

PD06-3000002 - PD06-5200008

My Bike
XL 600 V TRANSALP
1987 - 1993
Find another bike
Specifications *
Cylinders:
2
hp/kW:
50/37
Vehicle weight (kg):
202
Seat height (mm):
850
Valve clearance (intake):
88:0,10 89-:0,15MM
Valve clearance (exhaust):
88:0,10 89-:0,20MM
Engine idle speed:
1300 ± 100 U/MIN
Carburettor air screw:
2,25 AUSDREHUNGEN
Tyre pressure (front):
2,0 BAR
Tyre pressure (rear):
2,0 BAR
Spark plug 1:
NGK DPR8EA-9
Spark plug 2:
NGK DPR8EIX-9
Electrode gap:
0,9 MM
Fork tube diam.:
41 MM TELEGABEL
Front/rear sprockets:
15/47 ZÄHNE
Chain/Final drive:
118 GLIEDER
Capacities *
Fork oil per rod:
550 ML SAE 10W
Engine oil w/o filter:
2,2 L SAE 10W-40
Engine oil with filter:
2,4 L API SE-SF
Brake fluid:
DOT 4
Fuel:
18,0 LITER
Coolant:
-88:1,8L 89-:2,0L
* We acquire the data with care, but without any guarantee
Louis has taken great care in compiling the specifications and associated products. They apply to the model of the selected vehicle that is sold in Germany. The specifications of models sold in other countries may differ. Louis does not accept any responsibility for the accuracy of the information provided. Prior to installation, you should consult your motorcycle's handbook and/or seek information from the manufacturer.
