Spare parts and accessories for YAMAHA XT 1200 Z SUPER TÉNÉRÉ (EURO 4) - DP071

My Bike
XT 1200 Z SUPER TÉNÉRÉ (EURO 4)
2017 - 2020
Find another bike
Specifications *
Cylinders:
2
hp/kW:
112/82
Vehicle weight (kg):
257
Seat height (mm):
845
Valve clearance (intake):
KALT 0,10-0,16 MM
Valve clearance (exhaust):
KALT 0,22-0,28 MM
Engine idle speed:
1100 ± 50 U/MIN
Carburettor air screw:
EINSPRITZUNG
Tyre pressure (front):
2,25 BAR
Tyre pressure (rear):
2,5 (2,9) BAR
Spark plug 1:
NGK CPR8EB-9
Spark plug 2:
Electrode gap:
0,8-0,9 MM
Fork tube diam.:
43 MM USD-GABEL
Front/rear sprockets:
Chain/Final drive:
KARDAN
Capacities *
Fork oil per rod:
485 ML
Engine oil w/o filter:
3,1 L SAE 10W-40
Engine oil with filter:
3,4 L MIN. API SG
Gear oil:
Primary oil:
Brake fluid:
DOT 4
Final drive oil:
200 ML 80 API GL-4
Fuel:
23,0 LITER
Coolant:
CA. 2,1 LITER
* We acquire the data with care, but without any guarantee
Louis has taken great care in compiling the specifications and associated products. They apply to the model of the selected vehicle that is sold in Germany. The specifications of models sold in other countries may differ. Louis does not accept any responsibility for the accuracy of the information provided. Prior to installation, you should consult your motorcycle's handbook and/or seek information from the manufacturer.
