Spare parts and accessories for YAMAHA XT 500 - 1U6

My Bike
XT 500
1978 - 1989
Find another bike
Specifications *
Cylinders:
1
hp/kW:
32/24
Vehicle weight (kg):
141
Seat height (mm):
830
Valve clearance (intake):
KALT 0,07-0,12 MM
Valve clearance (exhaust):
KALT 0,12-0,17 MM
Engine idle speed:
1150-1250 U/MIN
Carburettor air screw:
11/8 AUSDREHUNGEN
Tyre pressure (front):
1,3 (1,9) BAR
Tyre pressure (rear):
1,8 (2,1) BAR
Spark plug 1:
NGK BP7ES
Spark plug 2:
NGK BPR7EIX
Electrode gap:
0,8 MM
Fork tube diam.:
36 MM TELEGABEL
Front/rear sprockets:
16/42 ZÄHNE
Chain/Final drive:
100 GLIEDER
Capacities *
Fork oil per rod:
238 ML SAE 10W
Engine oil w/o filter:
2,0 L SAE 20W-40
Engine oil with filter:
2,2 L MIN. API SE
Gear oil:
Primary oil:
Brake fluid:
MECH.TROMMELBREMSE
Final drive oil:
Fuel:
8,8 LITER
Coolant:
LUFTGEKÜHLT
* We acquire the data with care, but without any guarantee
Louis has taken great care in compiling the specifications and associated products. They apply to the model of the selected vehicle that is sold in Germany. The specifications of models sold in other countries may differ. Louis does not accept any responsibility for the accuracy of the information provided. Prior to installation, you should consult your motorcycle's handbook and/or seek information from the manufacturer.
