Spare parts and accessories for YAMAHA XVZ 13 TD VENTURE - 3JS

My Bike
XVZ 13 TD VENTURE
1989 - 1992
Find another bike
Specifications *
Engine size:
1294
Cylinders:
4
hp/kW:
97/71
Vehicle weight (kg):
340
Seat height (mm):
785
Valve clearance (intake):
KALT 0,11-0,15 MM
Valve clearance (exhaust):
KALT 0,16-0,20 MM
Engine idle speed:
1000 ± 50 U/MIN
Carburettor air screw:
2 AUSDREHUNGEN
Tyre pressure (front):
2,4 BAR
Tyre pressure (rear):
2,9 BAR
Spark plug 1:
NGK DPR8EA-9
Spark plug 2:
NGK DPR8EIX-9
Electrode gap:
0,9 MM
Fork tube diam.:
40 MM TELEGABEL
Chain/Final drive:
KARDAN
Capacities *
Fork oil per rod:
409 ML SAE 10W
Engine oil w/o filter:
3,5 L SAE 10W-40
Engine oil with filter:
3,8 L MIN. API SE
Brake fluid:
DOT 4
Final drive oil:
200 ML SAE 80 GL-4
Fuel:
20,0 LITER
Coolant:
2,8 LITER
* We acquire the data with care, but without any guarantee
Louis has taken great care in compiling the specifications and associated products. They apply to the model of the selected vehicle that is sold in Germany. The specifications of models sold in other countries may differ. Louis does not accept any responsibility for the accuracy of the information provided. Prior to installation, you should consult your motorcycle's handbook and/or seek information from the manufacturer.

What's the used value for this Bike? Find used value via DAT GmbH

Data or products for your motorcycle missing from the database? Found an error? Please let us know. Go to form

4.000 Battery Charger,
Procharger
4.000 Battery Charger,
RRP €119.99 €89.991
5000 4T SAE 10W-40
Motul
5000 4T SAE 10W-40
RRP €39.99 €29.991
(1 l = €7.501)
7100 4T Engine Oil SAE 10W-40, 1 Liter
Motul
7100 4T Engine Oil SAE 10W-40, 1 Liter
€17.991
7100 4T Engine Oil, 4 Liter
Motul
7100 4T Engine Oil, 4 Liter
RRP €69.99 €54.471
(1 l = €13.621)
8900 chain lock
Abus
8900 chain lock
RRP €60.95 €29.951
Aluminium washer set for oil
Louis
Aluminium washer set for oil
from €2.991
Bike Guardian
Midland
Bike Guardian
RRP €139.90 €104.901
Brake Fluid DOT 3 & 4, 0,5L
Motul
Brake Fluid DOT 3 & 4, 0,5L
RRP €7.99 €5.901
(1 l = €11.801)
BRAKE FLUID DOT 4
Louis Tech
BRAKE FLUID DOT 4
€11.991
Brake Fluid DOT 4 LV
Motul
Brake Fluid DOT 4 LV
€6.991
(1 l = €13.981)
NEW
Brake Fluid DOT4
TRW
Brake Fluid DOT4
€4.991
(1 l = €19.961)
Brake Light Switch
JMP
Brake Light Switch
RRP €4.99 from €2.991
Brake-Pads Sinter with ABE
TRW
Brake-Pads Sinter with ABE
from €34.951
Brakepads Organic
Brembo
Brakepads Organic
RRP €19.99 from €15.991
Brakepads Organic
TRW
Brakepads Organic
from €25.951
Breakdown kit
Louis Tech
Breakdown kit
€19.991
CARGO NET
Joubert
CARGO NET
€8.991
Copper ring set for oil
Louis
Copper ring set for oil
from €1.991
CORDLESS TYRE PUMP
Bosch
CORDLESS TYRE PUMP
RRP €77.70 €69.991
Detecto 7000 RS1 V2 Louis Edition
Abus
Detecto 7000 RS1 V2 Louis Edition
RRP €139.95 €99.951
Digital tyre pressure gauge
Craft-Meyer
Digital tyre pressure gauge
€9.991
Engine Oil 3000 4T SAE 10W-40, 1 Liter
Motul
Engine Oil 3000 4T SAE 10W-40, 1 Liter
€11.991
Engine Oil 3000 4T SAE 10W-40, 4 Liter
Motul
Engine Oil 3000 4T SAE 10W-40, 4 Liter
RRP €42.99 €32.001
(1 l = €8.001)
Engine Oil 4-Stroke 10W-40
Louis Oil
Engine Oil 4-Stroke 10W-40
RRP €29.99 from €24.991
Engine Oil 4-Stroke 10W-40
Louis Oil
Engine Oil 4-Stroke 10W-40
RRP €8.99 €6.991
Engine Oil 5100 4T SAE 10W-40, 1 Liter
Motul
Engine Oil 5100 4T SAE 10W-40, 1 Liter
€14.991
Engine Oil 5100 4T SAE 10W-40, 4 Liter
Motul
Engine Oil 5100 4T SAE 10W-40, 4 Liter
RRP €58.99 €45.591
(1 l = €11.401)
Engine Oil 5100 4T SAE 10W-50, 1 Liter
Motul
Engine Oil 5100 4T SAE 10W-50, 1 Liter
€14.991
Engine Oil 5100 4T SAE 10W-50, 4 Liter
Motul
Engine Oil 5100 4T SAE 10W-50, 4 Liter
RRP €58.99 €45.591
(1 l = €11.401)
engine oil SAE 10W-40, 4-stroke
Saito
engine oil SAE 10W-40, 4-stroke
RRP €24.99 €16.991
(1 l = €4.251)
Exhaust gasket
Athena
Exhaust gasket
from €2.991
Exhaust Gasket Muffler
Athena
Exhaust Gasket Muffler
from €7.991
Expert Fork Oil Technosynthese
Motul
Expert Fork Oil Technosynthese
RRP €17.99 from €16.901
Factory Line Fork Oil 10W, 1 litre
Motul
Factory Line Fork Oil 10W, 1 litre
RRP €27.99 €16.651
Fork Oil
Castrol
Fork Oil
RRP €9.99 €7.501
(1 l = €15.001)
Fork oil zero friction SAE 5W up to 20W
Wilbers
Fork oil zero friction SAE 5W up to 20W
€25.001
Fork Seal Set
Saito
Fork Seal Set
RRP €9.99 from €6.991
FORKOIL
Ravenol
FORKOIL
RRP €11.49 €9.991
Friction Plates Sets
TRW
Friction Plates Sets
RRP €40.95 from €39.991
Front-Fork Retaining
Front-Fork Retaining
RRP €5.99 from €3.991
fully synthetic fork oil
Öhlins
fully synthetic fork oil
from €25.991
gel batteries, FA / sealed
Delo
gel batteries, FA / sealed
RRP €39.99 from €29.991
Gel Battery
Saito
Gel Battery
from €19.991
Grand Prix 10W-40 Engine Oil, 4l
Castrol
Grand Prix 10W-40 Engine Oil, 4l
€39.991
(1 l = €10.001)
IRIDIUM SPARK PLUG
NGK
IRIDIUM SPARK PLUG
RRP €14.99 from €12.991
Lithium-Ion Batteries
Delo
Lithium-Ion Batteries
RRP €69.99 from €51.991
Lucas Brake Discs
TRW
Lucas Brake Discs
from €63.951
Megnetic Oil Drain Plug
Louis
Megnetic Oil Drain Plug
from €6.991
